| Brand | Thermaltake |
|---|---|
| Series | A500 Aluminum TG |
| Model | CA-1L3-00M9WN-00 |
| Internal 3.5" Drive Bays | 2.5” or 3.5” x 4 (HDD Cage) |
|---|---|
| Internal 2.5" Drive Bays | 2.5” or 3.5” x 2 (HDD Cage); 2.5” x 1(HDD Bracket) |
| Front Ports | USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, Type-C x 1 |
|---|
| Fan Options | Front: 3 x 120mm , 3 x 140mm Top: 3 x 120mm , 2 x 140mm Rear:
1 x 120mm |
|---|---|
| Radiator Options | Front: 1 x 360mm , 1 x 420mm Top: 1 x 360mm , 1 x 280mm Rear:
1 x 120mm |
| Max GPU Length | VGA length limitation: 310mm(With HDD Rack) 410mm(Without HDD Rack) |
|---|---|
| Max CPU Cooler Height | CPU cooler height limitation: 200mm |
| Max PSU Length | PSU length limitation: 220mm |
| Dimensions (H x W x D) | 560 x 236 x 510 mm
(22 x 9.3 x 20.1 inch) |
| Weight | 14.82 kg / 32.67 lb |
